Allen Bradley PowerFlex 400 Drives Product Selection

Oct 17,2022 | simplybuy industrial

PowerFlex 400 Drives

Drive Ratings					Catalog Number	Frame Size
Input Voltage	Normal Duty		Output Current (Amps)
Input Voltage	kW	HP	45°C	50°C
240V 50/60 Hz 3-Phase	2.2	3.0	12	12	22C-B012N103	C
	3.7	5.0	17.5	17.5	22C-B017N103	C
	5.5	7.5	24	24	22C-B024N103	C
	7.5	10	33	33	22C-B033N103	C
	11	15	49	49	22C-B049A103	D
	15	20	65	65	22C-B065A103	D
	18.5	25	75	75	22C-B075A103	D
	22	30	90	81	22C-B090A103	D
	30	40	120	120	22C-B120A103	E
	37	50	145	130	22C-B145A103	E
480V 50/60 Hz 3-Phase	2.2	3.0	6	6	22C-D6P0N103	C
	4.0	5.0	10.5	10.5	22C-D010N103	C
	5.5	7.5	12	12	22C-D012N103	C
	7.5	10	17	17	22C-D017N103	C
	11	15	22	22	22C-D022N103	C
	15	20	30	27	22C-D030N103	C
	18.5	25	38	38	22C-D038A103	D
	22	30	45.5	45.5	22C-D045A103	D
	30	40	60	54	22C-D060A103	D
	37	50	72	72	22C-D072A103	E
	45	60	88	88	22C-D088A103	E
	55	75	105	105	22C-D105A103	E
	75	100	142	128	22C-D142A103	E
	90	125	170	170	22C-D170A103	F
	110	150	208	208	22C-D208A103	F
	132	200	260	260	22C-D260A103	G
	160	250	310	290	22C-D310A103	G
	200	300	370	370	22C-D370A103	H
	250	350	460	410	22C-D460A103	H
240V 50/60 Hz 3-Phase	2.2	3	12	12	22C-B012F103	C
	3.7	5	17.5	17.5	22C-B017F103	C
	5.5	7.5	24	24	22C-B024F103	C
	7.5	10	33	33	22C-B033F103	C
480V 50/60 Hz 3-Phase	2.2	3	6	6	22C-D6P0F103	C
	4.0	5	10	10	22C-D010F103	C
	5.5	7.5	12	12	22C-D012F103	C
	7.5	10	17	17	22C-D017F103	C
	11	15	22	22	22C-D022F103(1)	C
	15	20	30	27	22C-D030F103(1)	C
(1) A DC bus inductor is required.

Catalog Number Description
