range of product | Harmony Electromechanical Relays Harmony Timer Relays |
---|---|
product or component type | Socket |
contact terminal arrangement | Mixed |
product compatibility | Plug-in relay RXM with 2 C/O contact Plug-in relay RXM with 4 C/O contact |
shape of pin | Flat |
device short name | RXZ |
sale per indivisible quantity | 10 |
[Ith] conventional free air thermal current | 10 A |
[Ue] rated operational voltage | < 250 V |
connections - terminals | Screw clamp terminals, 1 x 0.25...1 x 1 mm² (AWG 22...AWG 17) flexible with cable end Screw clamp terminals, 2 x 0.25...2 x 1 mm² (AWG 22...AWG 17) flexible with cable end Screw clamp terminals, 1 x 0.5...1 x 1.5 mm² (AWG 20...AWG 16) solid without cable end Screw clamp terminals, 2 x 0.5...2 x 1.5 mm² (AWG 20...AWG 16) solid without cable end |
tightening torque | < 1 N.m for M3 screw(s) |
fixing mode | By screw (panel) Clip-on (35 mm symmetrical DIN rail) |
marking | CE |
width | 30 mm |
net weight | 0.048 kg |
