| Product Series | ComPacT new generation |
|---|---|
| product name | ComPacT NSXm new generation |
| Product short name | NSX100m 100NA |
| product type | Load switch |
| Applications | Isolation |
| Rated current[In] | 100 A |
| Electrode description | 3P 3D |
| Control type | Direct handle rotation handle extension rotation handle |
| Installation type | Screw fixing (base plate mounting) snap locking (DIN rail mounting) |
| Grid type | AC |
| Grid frequency | 50/60 Hz |
| Rated short-time withstand current [Icw] | 1500 A at 1 s (Icw) 1500 A at 3 s (Icw) 335 A at 20 s (Icw) |
| [Icu] rated ultimate breaking capacity | Icm 2.13 kA conforming to EN/IEC 60947-3 |
| Rated operating voltage [Ue] | 690 V AC 50/60 Hz conforming to IEC 60947-3 |
| Rated impulse withstand voltage [Uimp] | 8 kV conforming to IEC 60947-3 |
| Rated insulation voltage [Ui] | 800 V conforming to IEC 60947-3 |
| protection type | No protection |
| Isolation function | Suitable for compliance with EN/IEC 60947-3 |
| Usage categories | AC-22A AC-23A |
