Manufacturer |
Rockwell Automation |
Mounting: |
DIN Rail |
Number of Inputs: |
Thirty-Two (32), sinking inputs |
Terminal base: |
1794-TB3, 1794-TB3S ,1794-TBN, 1794-TB3K, 1794-TB3SK and 1794-TBNK |
Keyswitch Position: |
2 |
ON state Voltage, min: |
10VDC |
ON state Voltage, max. |
31.2VDC |
OFF state Voltage, max: |
24VDC |
Indicators: |
32 Yellow status indicators |
Product Description: |
Flex IO DC Input Module |
Wire Size: |
Determined by installed terminal base |
Dimensions: |
94 x 94 x 69 mm (3.7 x 3.7 x 2.7 in.) |
Enclosure type rating: |
None (open-style) |
Operating Temperature: |
0 to 55 C (32 to 131 F) |
Storage Temperature: |
-40 to 85 C (-40 to 185 F) |
Vibration: |
5g @ 10 to 500 Hz |
Operating Shock: |
30 g |
Product Family: |
Flex I/O |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1794-IB32 |
Product Type |
Flex I/O Digital Input Modules |
Inputs |
32 Current Sinking |
On-state Voltage min. |
19.2 Volts DC |
On-state Voltage max. |
31.2 Volts DC |
On-state Current (minimum) |
2.0 milliamps |
On-state Current (maximum) |
6.0 milliamps |
Off-state Voltage (maximum) |
5 Volts DC |
Off-state Current (maximum) |
1.5 milliamps |
Nominal Input Impedance |
22.2 k? |
Flexbus Current |
30 milliamps at 5 Volts DC |
Power Dissipation |
6.0 Watts at 31.2 Volts DC maximum |
UPC |
10612598279903 |
