Manufacturer | Rockwell Automation / Allen-Bradley |
Part Number/Catalog No. | 1769-L36ERM |
Product Line | CompactLogix |
Product Type: | Programmable Automation Controller |
Module Type | Processor Module |
Part Number: | 1769-L30ERM |
Communication ports: | 2 Ethernet I/P; 1 USB |
Memory | 3 MB |
Motion Control over Ethernet I/P: | Included |
Shipping Weight | 2 pounds |
Integrated Motion: | 16 Axes |
Shipping Dimensions | 8 x 8 x 5 inches |
Maximum number of I/O modules supported: | 30 Modules |
Series | A and B |
Maximum number of I/O banks supported: | 3 banks |
Wire Type | Copper-90 degrees Celsius |
Power supply distance rating: | 4 |
Wire Size (Solid) | 22 to 14 AWG |
Vibration: | Operating: 10 to 500 Hz, 5G, 0.030 in. peak-to-peak |
Wire Size (Stranded) | 22 to 16 AWG |
Operating Temperature: | 0° to +60°C (+32° to +140°F) |
Shock rating | 20 G (operating) |
UPC | 10885630101238 |
Programming Language: | Relay ladder, Structured Text, Function block, SFC |
Non-Volatile memory: | 1784-SD1 card with 1 Gb of available memory (shipped with controller) ; 1784-SD2 card with 2 Gb of available memory (available for separate ordering) |
Mounting: | DIN Rail; Panel Mounting |
