Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Dimensions | Height: 90 mm 104 mm (with DIN latch open); Width: 160 mm; Depth: 87 mm |
Supported Protocols | DF1, DH-485, ASCII, MODBUS |
Communication Ports | One (1) 8-Pin mini-DIN serial port; One (1) Programming port |
Load Current | 10A, minimum |
Mechanical Cycles | 20,000,000 |
Relay Contact Rating | 24-125VDC; 120-240VAC |
Output Circuit Type | Relay; FET |
Input Circuit Type | 24 VDC |
No. of Outputs | (8) relay; (7) 24V dc FET; (1) high-speed 24V dc FET |
No. of Inputs | (20) 24V dc; (4) fast 24V dc |
Power Supply | 24VDC |
Shipping Weight | 2.4 pounds |
Part Number/Catalog No. | 1762-L40BXBR |
Ambient Operating Temp | 0 to 55 degrees Celsius |
Power Supply Usage | 82 VA |
Power supply inrush current | 120V ac: 25A for 8 ms; 240V ac: 40A for 4 ms |
Series | MicroLogix 1200 |
Product Type | Programmable Controller |
Outputs | (8) Relay, (7) 24V DC FET, and (1) High-Speed 24V DC FET |
Input Power | 24V DC |
Inputs | (20) 24V DC and (4) Fast 24V DC |
Inrush Input Currents | 150A at 30 seconds |
Power Consumption | 40 Watts |
Output Currents | 600mA at 5 Volts DC and 500mA at 24 Volts DC |
Heat Dissipation | 27.9 Watts |
Operating Temperature | 32 to 131 degrees Fahrenheit |
Weight | 1.1 kilograms |
Operating Shock | 30 G |
Vibration | 5G at 10 to 500 Hertz |
UPC | 10781180463881 |
