Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Product Family: | MicroLogix 1200 |
Analog Normal Operating Range | 0 to 10 Volts DC |
Part Number/Catalog No. | 1762-IF2OF2 |
Product Type: | Analog Input / Output Module |
Inputs | Two (2) Analog Voltage and Current |
Input / Output current range: | Current: 4…20 mA |
DA Converter Type | Resistor String |
Dimensions | 90 x 87 x 40 millimeters |
Input / Output voltage range: | Voltage: 0…10V dc |
Resolution: | 12 Bit |
UPC | 10612598207197 |
Converter Type | Successive Approximation |
Channel Diagnostics: | Over- or under-range by bit reporting, process alarms |
Temperature, operating: | -20…55 °C (-4…131 °F) |
Temperature, nonoperating: | -40…85 °C (-40…185 °F |
Shipping Weight | 0.53 pounds |
