Manufacturer |
Rockwell Automation |
Removable Terminal Block |
1756-TBCH; 1756-TBS6H |
Enclosure type rating |
None (open-style) |
Power Dissipation |
4.5 W @ 60 °C (140 °F) |
Backplane Current, 24VDC |
2 mA |
Total backplane Power |
4.4 W |
Current draw @ 5.1V |
150 mA |
Operating Voltage range |
5…125V DC; 10…240V AC |
Contact form |
Normally Open (N.O.) |
No. of outputs |
Sixteen (16), individually isolated channels |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1756-OW16I |
Series |
ControlLogix |
Module Type |
Digital DC Sourcing Output |
Outputs |
16-Point Individually Isolated |
Operating Voltage |
10-265 Volts AC, 5-150 Volts DC |
Output Current |
2, 0.5, 0.25 Amps |
Maximum Output Delay Time |
10 milliseconds |
Contact Output |
13 N.O. |
Power Dissipation (Max) |
4.5 Watts at 60 Celsius |
Removeable Terminal Block(s) |
1756-TBCH, 1756-TBS6H |
Isolation Voltage |
50 Volts Continuous |
Enclosure |
None |
UPC |
61259817146 |
UPC |
10612598171467 |
