Manufacturer |
Rockwell Automation |
Brand |
Allen-Bradley |
Part Number/Catalog No. |
1756-OB32 |
Series |
ControlLogix |
Module Type |
DC Output Module |
Outputs |
32-Point |
Voltage |
12-24 Volts DC Source |
Operating Voltage Range |
10-31.2 Volts DC |
Output Delay Time, OFF to ON |
60 µs nom/1 ms max |
Output Delay Time, ON to OFF |
200 µs nom/1 ms max |
Current per point |
0.5 A @ 50 °C (122 °F) linear derating 0.35 A @ 60 °C (140 °F) |
Current per module |
16 A @ 50 °C (122 °F) linear derating 10 A @ 60 °C (140 °F) |
Maximum Output Current Rating-Point |
0.5 Amps at 50 Celsius, 0.35 Amps at 60 Celsius |
Maximum Output Current Rating-Module |
16 Amps at 50 Celsius, 10 Amps at 60 Celsius |
UPC |
10662468702994 |
Power Dissipation (Max) |
4.8 Watts at 60 degrees Celsius |
Backplane Current at 5 Volts |
300 milliamps |
Removeable Terminal Block(s) |
1756-TBCH, 1756-TBS6H |
Isolation Voltage |
50 Volts Continuous |
Enclosure |
None |
