Manufacturer | Rockwell Automation |
Brand | Allen-Bradley |
Part Number/Catalog No. | 1756-OA16 |
Series | ControlLogix |
Module Type | Digital AC Output Module |
Outputs | 16-Points |
Voltage | 120-140 Volts AC |
No. of Outputs | Sixteen (16) mechanically fused |
Voltage Category | 120 / 240 Volts AC |
Maximum Output Current Rating-Point | 0.5 Amps at 60 degrees Celsius |
Operating Voltage Range | 74-265 Volts AC |
Maximum Output Current Rating-Module | 4 Amps at 60 degrees Celsius |
Output Delay Time | Programmable 9.3 or 11 milliseconds |
Current per point | 0.5 A @ 60 °C (140 °F) |
Current per module | 4 A @ 60 °C (140 °F) |
Removeable Terminal Block(s) | 1756-TBNH, 1756-TBSH |
Isolation Voltage | 50 Volts Continuous |
Power Dissipation (Max) | 6.5 W @ 60 °C (140 °F) |
Enclosure | None |
Backplane Current at 5 Volts | 400 mA |
UPC | 10612598171368 |
Backplane Current at 24 Volts | 2 mA |
Removable Terminal Block(s) | 1756-TBCH, 1756-TBSH |
